VHS10 professional video head with 75mm semi-semisphere

Professional fluid head for video camera

The VHS10 fluid head of Sirui It offers quick configurations and fluid movements for professional video cameras, DSLRs and mirrorless cameras with up to 10 kg weight. It is equipped with a 7-level counterbalance system, 3 + 0 levels of resistance to inclination and rotation, a 75 mm semi-semisphere base, a side loading plate and a quick release fixing handle.

7-level counterbalance

The 7-level counterbalance system of the VHS10 allows you to lock the head in almost all positions without this back to the initial level when unwanted. This head is suitable for use with cameras with weight up to 5 kg.

Side loading camera plate

• The handful-loaded side loading camera plate included is equipped with a positioning pin and 1/4 "-20 and 3/8" -16 mounting screws.
• Security functions include a safety block, rubber padding and a safety pin.

Quick release fasteners handle

• The quick release fixing system guarantees a secure grip in just 2 seconds.
• It eliminates the need to tip with traditional fixing systems that tend to loosen over time.

Resistant 75 mm semisphere design

• The 75 mm semi-shaped base allows you to quickly level the frame without adjusting the tripod legs.
• The aluminum alloy structure guarantees robust durability and performance.
• The panoramic handle included can be used both on the right side and on the left side of the head.

Articles included

• Professional fluid head Sirui VHS10
• Panoramic handle
• Quick release plate
• 1/4 "-20 screw
• 3/8 "-16 screw
• Quick release fixing
• 6-year limited manufacturer's warranty

Technical details:
- Camera mounting: 1/4 "-20 and 3/8" -16 screws (quick release with sliding balancing plate)
- Type of head: fluid head
- Basic attack: 75 mm hemisphere
- counterbalance: 3-level incremental plus 0
- Dimensions: Height: 11.5 "/ 292.00 mm, Basic diameter: 3.0" / 75.00 mm
- Resistance control: Yes
- independent overview block: yes
- Independent inclination block: Yes
- Vertical inclination: from + 90 ° to -70 °
- Side inclination: No
- Load capacity: 10 kg
- Bubble level: Yes (illuminated)
- Weight: 2.5 kg
